Aluminium Alloyed Ingots

Aluminium Alloyed Ingots

We make Aluminum Alloy Ingots (LM-2, LM-4, LM-6) for Gravity and Sand Casting, as well as Pressure Die Casting Alloys (LM-13, LM-14, LM-24, ADC-12, ALSI-132) that meet Indian and International standards. We can also make custom Aluminum Alloy Ingots and Billets for our customers as per their requirements and needs.

Specification

We at Sharvaya Metals Pvt Ltd, are committed & specialized in manufacturing all types of Aluminium Alloyed Ingots and Billets. Our aluminium Alloyed Ingots are manufactured to meet Indian as well as International standards such as – JIS, BS, DIN ASTM & IS. Mentioned below is our Aluminium Alloy chemical composition chart.

DESCRIPTION Weight Height Width Length
ALUMINIUM ALLOY INGOTS 5 – 10 KGS 65mm 120mm 610mm

We are committed to manufacturing and providing our customized services as per the specific requirements of our customers.

Chemical Composition Chart of various Aluminium Alloyed Ingots we supply

Place Annexure 1

Sr.No Alloy Silicon Iron Copper Manganese Mangesium
2 LM 4 4.-6 0.8MAX 2.0-4.0 0.2-0.6 0.15Max
3 LM 6 10-13 0.6MAX 0.1Max 0.5Max 0.1Max
4 LM 9 10-13 0.6MAX 0.1Max 0.3-0.7 0.2-0.6
5 LM 13 10-13 1.0MAX 0.7-1.5 0.5Max 0.8-1.5
6 LM 14 0.6Max 0.6MAX 3.5-4.5 0.6Max 1.2-1.7
7 LM 16 4.5-5.5 0.4MAX 1.2-1.5 0.1-1.5 0.4-0.6
8 LM 20 10-13 1.0MAX 0.4Max 0.5Max 0.2Max
9 LM 24 7.5-9.5 1.0MAX 3.0-4.0 0.5Max 0.3Max
10 LM 25 6.5-7.5 0.5MAX 0.1Max 0.3Max 0.2-0.45
11 LM 26 8.5-10.5 1.2Max 2.0-4.0 0.5Max 0.5-1.5
12 LM 30 16-18 1.1Max 4.0-5.0 0.3Max 0.4-0.7
13 ALSi9Cu3 8.0-11.0 0.8Max 2.0-3.5 0.1-0.4  0.1-0.5
14 ALSi 12 10.5-13.5 0.55Max 0.1Max 0.4Max 0.1Max
15 ALSi 12Cu 10.5-13.5 0.8Max 1.0Max 0.2-0.45  0.3Max
16 ALSi 132 11-12.5 0.7-1.0 1.75-2.5 0.5Max  0.2-0.5
17 ADC-6 1.0Max 1.0Max 0.1Max 0.4-0.6  2.6-4.0
18 ADC-10 7.5-9.5 0.9Max 2.0-4.0 0.5Max  0.3Max
19 ADC-12 9.6-12.0 1.3Max 1.5-3.5 0.5Max 0.3Max
20 356 6.5-7.5 0.5Max 0.25Max 0.35Max 0.25-0.45
21 AC4B 7.0-1.0 0.5Max 2.0-4.0 0.3Max  0.15-0.25
22 ALSi9MnMg 8.5-10.0 0.7Max 0.4-0.6 0.3-0.4 0.2Max



Sr No Zinc Nickle Titanium Tin Lead Aluminium
1 2.0Max 0.5Max 0.2Max – 0.3Max Balance
2 0.5Max 0.3Max 0.2Max – 0.1Max Balance
3 0.1Max 0.1Max 0.1Max – 0.1Max Balance
4 0.1Max 0.1Max 0.2Max – 0.1Max Balance
5 0.5Max 1.5Max 0.2Max – 0.1Max Balance
6 0.1Max 1.8-2.3Max 0.05Max – 0.05Max Balance
7 0.1Max 0.1Max – – – Balance
8 0.2Max 0.1Max 0.2Max – 0.1Max Balance
9 1.5Max 0.5Max 0.2Max – 0.3Max Balance
10 0.1Max 1.5Max 0.2Max – 0.1Max Balance
11 1.0Max 0.3Max 0.2Max – 0.2Max Balance
12 0.2Max 0.1Max 0.2Max – 0.1Max Balance
13 1.0Max 0.3Max 0.15Max 0.1Max 0.2Max Balance
14 0.1Max 0.15Max 0.15Max 0.1Max – Balance
15 0.5Max 0.2Max 0.15Max 0.1Max 0.2Max Balance
16 1.0Max 0.15Max 0.1Max – 0.1Max Balance
17 0.4Max 0.1Max – 0.1Max – Balance
18 1.0Max 0.5Max – 0.3Max – Balance
19 1.0Max 0.Max – 0.3Max – Balance
20 0.35Max – 0.20Max – – Balance
21 0.3Max 0.35Max 0.10Max – – Balance
22 0.2Max 0.05-0.20 – – – Balance
